IP68 Junction Boxes Geo

Geo-Amphibox

IP68 Stainless steel junction boxes Geo-Amphibox Series made of stainless steel AISI 304L or AISI 316L, combine a number of features ideal for electrical and electronic applications where security and perfect sealing against dust and water are essential it can be place in indoor or outdoor areas.

Submersible 1 meter during 7 days.

IP68 Enclosures are widely used for housing vital electronic control and test equipment for an enclosure which will withstand harsh environmental conditions, this hardwearing, IP68 junction boxes range, may be highly suitable.

This product has the following certificates

Description

Stainless steel junction box Geo Amphibox© Series IP68 made of stainless steel AISI 304L or AISI 316L, combine a number of features ideal for electrical and electronic applications where security and perfect sealing against dust and water are essential it can be place in indoor or outdoor areas. Submersible 1 meter during 7 days.

Enclosures IP68 are widely used for housing vital electronic control and test equipment for an enclosure which will withstand harsh environmental conditions, this hardwearing, IP68 enclosure range, may be highly suitable.

Download all documents and certificates

Do you need extra info?
In DELVALLE, WE make IT EASY for you

Discover the advantages

Sealing allows total protection against dust and waterproof in 1 meter during 7 days.
This type of boxes combine corrosion resistance and the highest market impact IK10.
The manufacture of the stainless steel monobloc allows sealing and the maximum resistance.
Safe and resistant in hard and aggresive environments.
Supplied with protective film prevents scratches and abrasions during handling.
Monobloc shape giving perfect sealing and impact resistance
Strength, durability and long life.
Spacious interior that simplifies the connection operations
Inox AISI 304L or AISI 316L.
Unlosable screws.
Ideal enclosure for outdoor and adverse conditions.

Regulations

IP68 rated Norm IEC EN 62208 and EN 60529. Submersible 1 meter during 7 days.
Maximum IK10 resistance Norm IEC 62208 and EN 50102.
CE standards Low Voltage Directive 2014/35/UE.
Corrosion resistance C5M, according to ISO 12944 (AISI 316).
IP68 (w) Corrosion areas.
Compliant RoHS Directive 2011/65/UE.
Maximum voltage 1000 V.
Temperature resistant: -40°C +100°C (short time +160°C).
Option silicone gasket: from -60°C to +180°C (short time up to +350°C).

Applications

This combination of features make it ideal for inner housing of electronic and electrical in harsh environments weathering, marine, oil & gas, water where the level of protection should be provided by high sensitive components in applications such as food preparation, washing areas, both inside and out.
